One of 5g cell radio module used by E-Lins 5g industrial router
Key Benefits
• Standard M.2 (NGFF) Data-card form factor
• Support of 5G Sub-6 FDD and TDD and mmWave
• Support of SA & NSA operations, 5G core network Opt. 3a/3x and Option 2
• 4G/5G Rel. 15
• 4G Cat. 20 up to 7CAs
• 3G HSPA+ Rel 18
• State of the art GNSS receive
- Product Details
- Specifications
- Download
- Order Model
Telit-FN980m is one of the 5g cell radio module used by E-Lins 5g industrial router.
Advanced LTE/5G LTE Data Card
Enabling a new generation of 5G state of the art data cards featuring both Sub-6 and mmWave technologies with LTE, WCDMA and GNSS support.
Industrial-grade M.2 form factor suitable - among others - for the following applications: High Power Fixed Wireless access, enterprise routers and gateways, indoor/outdoor CPE, video broadcasting and surveillance. Support of Qualcomm QTM525 and QTM527 mmWave antennas
Product Features
• 5G Sub-6 and mm Wave FDD and TDD, SA & NSA operations
• 5G core network Opt. 3a/3x and Opt. 2 • 4G: 7CA, up to 20 layers DL / 3CA UL, 256 QAM DL/UL
• 3G: HSPA+ Rel. 8 (DL/UL 42/11 Mbps)
• GNSS: gpsOne Gen9 L1 band on dedicated RF connector, L5 shared with cellular
• Voice support: VoLTE, VoNR (under evaluation), PCM audio over USB
• 4 antenna connectors for LTE/Sub-6
• 4 mmWave antennas supported
• 5G FR1 Bands: n1, n2, n3, n5, n7, n12, n14, n20, n28, n30, n41, n66, n71, n77, n78, n79
• 5G FR2 Bands: n257, n258, n260, 261
• LTE Bands: 1, 2, 3, 4, 5, 8, 9, 12, 13, 14, 17, 18 19, 20, 26, 28, 71, 25, 66, 39, 29 (DL), 30, 32, 7, 38, 40, 41, 42, 43, 46 (LAA), 48(CBRS), 34, 27
• WCDMA Bands: 5, 8, 3, 4, 2, 1, 9, 19
• 5G 4x4 MIMO support on bands n1, n2, n7, n66, n3, n77, n78, n79, n41 and n30
• 4G 4x4 MIMO support on bands 32, 4, 66, 3, 2, 25, 1, 30, 40, 41, 7, 43, 42, 46, 48
• Antenna types: 4x LTE/Sub-6 + 4x QTM525/527
• FOTA Support
• Dimensions: 30 x 50 x 3.5mm
Data Throughput
• 5G up to 5.5 DL/2.7 UL Gbps
• 4G up to 2.4 Gbps DL/211 Mbps UL
• 3G up to 42 DL/11 UL Mbps
